Micro-Lock Plus Connectors System

Micro-Lock Plus terminal retention force provides electrical reliability for applications in rugged environments. Rated at a 105˚C operating temperature with a wide range of current ratings, the Micro-Lock Plus Connector is ideal for general market applications. Rugged applications can be subject to shock, vibration or rough handling that can dislodge terminals and cause signal interference.

Micro-Lock Plus tin-bismuth plating offers reliability and lower applied costs. Tin plating can sometimes cause whiskering and signal intermittency, while more durable gold plating comes with a higher cost.

Micro-Lock Plus Connectors have a positive latch that provides an audible click, ensuring a secure mate. In microminiature wire-to-board applications, operators can sometimes mistakenly fail to ensure connectors are fully mated. This, in turn, can lead to end-product failure.

Features:

Micro-Lock Plus Connectors System

  • Smallest 1.25mm-pitch connector with positive lock

    Delivers secure mating retention without sacrificing compactness



  • Tin-bismuth terminals
    Prevents whiskering for a clean and uninterrupted signal
    Supports terminal ruggedness and reliability



  • Inner lock for dual-row versions; outer lock for single-row versions

    Strengthens lock for more reliable connection



  • Withstands up to 105˚C operating temperature

    Meets automotive industry requirements
    Withstands harsh environments



  • 2 to 42 circuits, single and dual rows, vertical and horizontal plug configurations

    Offers design flexibility



  • Wide positive latch that delivers audible click

    Provides secure mating retention
    Ensures proper mating



  • Robust metal solder tabs

    Provides secure PCB retention and strain relief to solder joints



  • Dual contact terminal design

    Offers secure contact and terminal retention


    Applications:

    Automotive

    • Internal connection with other units
    • Steering wheel, paddle shift, combination switches


    Consumer

    • Air conditioner
    • Desktop PCs
    • Drones
    • Gaming Machines
    • Laser printers
    • Power tools
    • Vacuum cleaners
    • White goods
